Dual Spindle Turn Mill Machine TCK700S | One-Setup Turn-Mill-Drill Processing
Dual Spindle Turn Mill Machine TCK700S | One-Setup Turn-Mill-Drill Processing
Place of Origin:
Tengzhou, Shandong
Brand Name:
JingOne Machine
Certification:
CE Certifications
Model Number:
TCK700S
Contact Us
Request A Quote
Product Details
CNC System:
Fanuc Oi-TF
Guide Ral:
Linear Guide
Max. Bar Capacity:
48 Mm
Max. Turning Length:
600 Mm
Spindle Speed:
50-3500 Rpm
Sub-spindle Speed:
50-3500 Rpm
Turret:
BMT55-12T
Chuck:
10'' Hydraulic Chuck
Payment & Shipping Terms
Minimum Order Quantity
1
Price
60000USD
Packaging Details
Plywood Case
Delivery Time
30 days
Payment Terms
T/T
Supply Ability
50 sent/month
RELATED PRODUCTS
CONTACT US
Contact Now
Product Description
Dual Spindle Turn Mill Machine TCK700S: One-Setup Machining Eliminates Production Delays
Model: TCK700S | Core Keyword: Dual spindle turn mill machine
Summary
Dual spindle turn mill machine TCK700S delivers one-setup turn-mill-drill processing to eliminate re-clamping errors and reduce production time by 25%.
Featuring a rigid integral slant bed, 15Kw dual spindles, and Taiwan roller linear guide rails, this model maintains consistent precision for complex auto and industrial parts.
Perfect for job shops and mid-volume manufacturers needing to maximize floor space with its compact 7sqm footprint.
Features
- One-setup turn-mill-drill integration eliminates re-clamping errors and reduces overall production cycles for complex components
- Integral slant bed cast from high-grade iron with hardened guideway for consistent precision over 10,000 hours of operation
- Dual 15Kw A2-6 spindles with 3500rpm stepless speed for high-speed, high-tolerance machining of ferrous and non-ferrous metals
- BMT55 turret with 12 tool stations and fast indexing time for uninterrupted production workflows
- Pre-embedded lubrication system to extend component lifespan and reduce unplanned downtime due to wear
Technical Specifications
| Parameter | Specification |
|---|---|
| Max. Swing Diameter over Bed | 700 mm |
| Max. Swing Diameter over cross slide | 350 mm |
| Max. turning length | 600 mm |
| Max. Bar capacity | 48 mm |
| Max. processing diameter(plate) | 280 mm |
| Spindle Nose | A2-6 |
| Spindle Bore Diameter | 65 mm |
| Main Motor Power | 15 Kw |
| Spindle Speed | 50-3500 rpm, stepless |
| Chuck | 8 inch hydraulic |
| X/Y/Z-axis rapid traverse | 18/6/18 rpm |
| X/Y/Z-axis motor torque | 15/6/15 Nm |
| X/Y/Z axis travel | 200/±45/650 mm |
| Guide rail | linear guide |
| Turret | BMT55 |
| Tool quantity | 12 stations |
| Tool shank size | 25x25/40 mm |
| Sub-spindle nose | A2-6 |
| Sub-spindle speed | 50-3500 rpm |
| Sub-spindle bore | 65 mm |
| Sub-spindle power | 15 Kw |
| Dimensions | 3200x2000x2200 mm |
| Net Weight | 4250 Kg |
Accessory Configurations
| Accessory |
|---|
| Chip Conveyor |
| Tool Setter |
| Automatic Door |
| Automatic Door Safety Device |
| Oil Mist Collector |
| Oil/Coolant Separator |
| Robot Interface |
| Bar Material Feeder |
| Blowing Device |
| Water Gun |
| Soft Jaws for Chuck |
| Live Tool Holders |
Logistics & Support
Packing: Sea-worthy plywood case with waterproof lining, reinforced with steel bands for long-distance shipping
Warranty: Full 12 months warranty covering core mechanical systems (spindle, gearbox, bed guideways)
Technical Support: Lifetime free technical support via email, video call, or on-site service (extra charge applies for on-site visits)
Export Coverage: Exported to 30+ countries including Germany, Australia, Brazil, USA, and Southeast Asian markets
Customs Documentation: Complete export documentation provided, including CE certificate, commercial invoice, packing list, and bill of lading
Request a tailored logistics plan for your TCK700S order today
FAQ
Q: How does one-setup machining on the TCK700S improve part accuracy?
A: The dual spindle turn mill machine eliminates re-clamping errors, ensuring consistent precision for complex auto and industrial components in a single setup.
Q: What is the maximum bar stock size the TCK700S can handle?
A: This dual spindle turn mill machine supports bar stock up to 48mm diameter, with 700mm swing over bed for large plate processing.
Q: Does the TCK700S offer automation options for high-volume production?
A: Yes, the dual spindle turn mill machine includes optional robot interface and bar feeder to streamline high-volume production lines.
