Q: What is the maximum load capacity and workpiece size of the CW6180B heavy duty lathe machine?

A: The JingOne CW6180B is an industrial horizontal metal lathe built to handle large-diameter and high-load component turning with high precision:

• It features an impressive 800mm swing diameter over bed and 480mm swing over carriage, allowing it to accommodate large industrial shafts, drums, and conical components.

• Thanks to its high-torsion premium cast iron bed, the CW6180B reliably supports a load capacity up to 2,000 kg (2 Tons) when configured with its standard steady rest and follow rest.

• The machine utilizes a 550mm ultra-wide induction-hardened guideway, which drastically reduces deflection and wear during extended, heavy material removal.

Q: How does the CW6180B industrial metal lathe maintain high rigidity during powerful cutting?

A: To prevent deflection and maintain strict tolerances under heavy cutting forces, the CW6180B utilizes a premium reinforced structural design:

• Ultra-Wide Hardened Bed: The high-torsion bed is cast from premium industrial cast iron and features a 550mm wide induction-hardened guideway, which maximizes wear resistance and long-term precision retention.

• 3-Support Spindle Structure: Unlike standard lathes, its spindle features a unique 3-support bearing design, providing exceptional stiffness and eliminating chatter during heavy-duty roughing.

• Vibration-Damping Technology: The implementation of polytetrafluoroethylene (PTFE) guide rail soft belts effectively absorbs cutting vibrations, ensuring smooth carriage travel and extending the service life of the machine.

Q: What threading and feeding capabilities does the CW6180B lathe offer for engineering workshops?

A:  The CW6180B functions as a highly versatile workhorse for contract workshops, providing diverse threading profiles and high efficiency:

• Comprehensive Threading: Driven by a versatile 18-speed wide speed range gearbox, it supports direct cutting of Metric, Imperial, Module, and Diametral Pitch threads without tedious manual gear changes.

• High Turning Accuracy: It guarantees superior geometric precision with a roundness error of ≤0.01mm.

• Reduced Idle Time: Outfitted with an integrated carriage rapid traverse mechanism that moves at 4000 mm/min, drastically minimizing non-cutting cycle times during tool positioning.
